Power Specification
DC Output:
Output power: 50 kW
Dynamic Power Sharing: 25 kW power granularity
Output voltage: 150 - 980 V
Output current (continuous): 150 A
Number of outlets: dual outlet
Power conversion efficiency: up to 96.5%
AC Input:
Nominal voltage: (CE): 400 Vac (NA): 480 Vac
Nominal input current (RMS): (CE): 77 A (NA): 64 A
Frequency: (CE): 50 Hz (± 10%) (NA): 60 Hz (± 10%)
Earthing systems: (CE): TN-C, TN-C-S, TN-S, TT (NA): WYE
Inlet cable size per phase (no neutral): multi core cable,
max. 28 mm (1.1 in) outer diameter
Power factor: > 0.99 at full load
Total Harmonic Distortion (THD): < 3%
Overvoltage category: III
SPD: (CE): Type 1 + 2 (NA): Type 1
SCCR: (CE): 50 kA (NA): 65 kA
Customer Interface
Display: Type: 21.5” HD full color anti-glare LCD; Brightness: 1300 nits;
Contrast: 5000:1; Interface: Touchscreen
HMI Configuration: Info modules: pricing, payment method, help content, idle state info
Branding modules: brand color and logo, app QR code, outro screen
Languages:
English, French, Spanish, German, Italian, Norwegian, Dutch
Connector Options:
CCS1/2 air-cooled, J3400 air-cooled
Cable Management
System (CMS):
Integrated linear force balancer CMS
Cable Options: Length: 4.2 m (13.8 ft); Reach: 3.9 m (12.8 ft)
Type: Air-cooled
Lighting: Roof: 360° dual RGBW LED strips; Gun holder: RGBW LEDs
Authentication Methods: RFID, Autocharge, Plug & Charge, credit/debit card, mobile app
RFID System: Mifare ISO 14443 A/B to part 4 and ISO 15693,
ISO 18092/ECMA-340 (NFC). Others available on request
(Calypso, Ultralight, PayPass, HID, and more)
Remote Management: Access control, configuration, diagnostics, software updates1
